fecostruct

The face-flush fecostruct structural glazing
meets exclusive design requirements

Transparency and surface flushness are an expression of current architecture. In fecostruct they find their structural equivalent. The bonding of the frameless face-flush glazing to the concealed aluminium glass frame with a width of only 20 mm is impressive. The result: perfectly flat glass walls that inspire and yet seem so natural.

lean as a whistle – Interior pane surfaces are cleaned at the factory

A special feature of feco double-glazing: It is supplied glazed on both sides. Under cleanest manufacturing conditions, the closed glass elements are produced, transported to the construction site and then mounted. Cleaning of the spaces between the panes at the construction site is a thing of the past. The inner surfaces of the panes are clean. Nonetheless, the fecostruct glass elements can be opened, for maintenance purposes without having to disassemble the elements due to the ingenious structural design.

Fall-protective feco double glazing

Face-flush double-glazing

Wall thickness 105 mm, flush with solid wall and door elements

Frameless Structural-glazing design

Bonding of the glass panes aluminium-base frame

Glazing frame without center joint in the inter-pane space

Bonding surface with a mere 20 mm circumferential facing width

Durable, UV-resistant, surface-homogeneous bonding

Base frame optionally aluminium natural anodized or powder-coated in a popular RAL color, bonding in aluminium color or black

Interior frame in real wood veneer, natural oak

Structural-glazing construction with a mere 20 mm facing width, bonding surface optionally in aluminium color or black

Prefabrication of double-glazed elements at the factory ensures cleanliness of glass interior surfaces

Blinds can be integrated center-lined in inter-pane space

Design possible as fall-protection glazing

Sound-insulation test values of glass wall Rw,P = 39 dB to 47 dB

Sound-insulation test values of top glazing partition wall Rw,P = 39 dB to 49 dB
